Once in happy with my drawings and everything is printing ok, i can put the STL files up On Cluts 3D (for a small fee) if anyone wants to have a go at printing one. The files will only be for personal use and Not to be printed and sold !

Updated.

What i have found out is they are possibly, K3, L4, L8 and F2 but i cant remember which one is which. Waiting on some info from Richard at IRRS, so should be able to say then which is which.

@Mol_PMB where did you get the axle driller with the nylon collars? I've been struggling to get the axles running free on the wagons I've been 3d printing and I think that drill would be the ticket.

4-4-0 Class J - Wheel Dia. 5' 7". Coupled wheelbase 7'1" ( O/A wheelbase 5'3" + 6' 4 1/2" + 7' 1") P - WD. 5' 7". Coupled wheelbase 8'. ( O/A wheelbase 5'3" + 6'10 1/2" + 8') P - WD. 6'7". Coupled wheelbase 8'. ( O/A wheelbase 5'3" + 6'10 1/2" + 8') PP - WD. 6' 7" . Coupled wheelbase 8'3". ( O/A wheelbase 5'3" + 6'10 1/2" + 8'3") Q - WD. 3'2"/ 6' 7" coupled wheelbase, 8' 8" ( O/A wheelbase 5'9" + 7'6 1/2" + 8'8") QL - WD. 3'2"/6' 7". Coupled wheelbase 9'3" ( O/A wheelbase 5'9" + 7'6 1/2" + 9'3") S - WD. 3'2" / 6' 7". Coupled wheelbase 7'6 1/2" + 9'6". ( O/A wheelbase 6' + 7'6 1/2" + 9'6") S2 - WD. 6' 7". Coupled wheelbase 7'6 1/2" + 9'6". ( O/A wheelbase 6' + 7'6 1/2" + 9'6") U - WD. 3'2" / 5' 9". Coupled wheelbase 8'3". ( O/A wheelbase 5'3" + 6'10 1/2" + 8'3") V - WD. 3'2" / 6' 7". Coupled wheelbase 10'8" (O/A wheelbase 6'6" + 7'7" + 10'8". Tender WD. 3'8". wheelbase 6'6" + 6'6" VS - WD. 3'2" / 6' 7". Coupled wheelbase 10'8" (O/A wheelbase 6'6" + 7'7" + 10'8". Tender WD. 3'8". Wheelbase 6'6" + 6'6" 0-6-0 C - WD. 5' (*4'7"). Coupled wheelbase 7'2" + 7'10" D - WD. 5' 1 3/4". Coupled wheelbase 7'3" + 8'3" E - WD. 5'. Coupled wheelbase 7'3" + 7'9" B - WD. 4' 7 1/2". Coupled wheelbase 7'3" + 7'3" A - WD. 4' 7". Coupled wheelbase 7'3" + 7'3" AL - WD. 4' 7". Coupled wheelbase 7'6" + 7'6" PG - WD. 4' 7 1/4". Coupled wheelbase 7'6" + 8'1" QG - WD. 4' 7 1/4".Coupled wheelbase 7'10" + 8'10" LQG - WD. 4' 7 1/4". Coupled wheelbase 7'10" + 8'10" NQG - WD. 4' 7". Coupled wheelbase 7'10" + 8'10" NLQG - WD. 4'7". Coupled wheelbase 7'10" + 8'10" UG - WD. 5' 1". Coupled wheelbase 7'3" + 8' 4 1/2" SG - WD. 5' 1". Coupled Wheelbase 8'1" + 8'10". SG2 - WD. 5' 1". Coupled Wheelbase 8'1" + 8'10". SG3 - WD. 5' 1". Coupled Wheelbase 8'1" + 8'10". Closest chassis i can find at the moment is a J39 , Coupled wheelbase 8' + 9'. Length of loco is similar but smoke box, boiler and cab is a fair bit bigger. Crane Tank - WD. 3'4". Coupled wheelbase 5' + 5' 0-6-0T BT - WD.4'7". Coupled wheelbase 6'6" ( O/A wheelbase 6' 9 1/2"" + 6'6') 2-4-2T JT - WD. 5'7". Coupled wheelbase 7'1" ( O/A wheelbase 7' + 7'1" + 6'5") 4-4-2T T1 - WD. 3'2" / 5' 9" / 4'. Coupled wheelbase 8'3" ( O/A wheelbase 5'3" + 6'10 1/2" + 8'3" + 8') T2 - WD. 3'2" / 5' 9" / 4'. Coupled wheelbase 8'3" ( O/A wheelbase 5'3" + 6'10 1/2" + 8'3" + 8') 4-2-2 JS - WD. 6'7". ( O/A wheelbase 5'3" + 6'8 1/2" + 7') 4-4-0 T BP - WD. 4'7". Coupled wheelbase 7'6" (O/A wheelbase 4' + 7'3" + 7'6") T - WD. 4' 7" BT - WD. 4' 7". Coupled wheelbase 6'6" (O/A wheelbase 5'3" + 5' 10 1/2" + 6'6") 0-6-4 T RT - WD. 4' 3"/ 2'8". Coupled wheelbase 7' + 6'6". ( O/A wheelbase 7'0" + 6'6" + 5' + 5'3") 2-4-0 G - WD. 5'7". Coupled wheelbase 7'1" ( O/A wheelbase 6'11" + 7'1") H - WD. 6' 0 1/2". Coupled wheelbase 8' ( O/A wheelbase 7' + 8') 2-4-2T JT - WD. 5' 7" 0-6-2T QGT - WD. 4' 7"/ 3'7 1/2". Coupled wheelbase 7'6" + 8'6". ( O/A wheelbase 7'6" + 8'6" + 6') QGT2 - WD. 4.7 1/4" / 3'8". Coupled wheelbase 7'6" + 8'10". ( O/A wheelbase 7'6" + 8'10" + 6') 0-4-0T No. 203 - WD. 2' 8 1/2" 0-4-2 K - WD. 5'1". Coupled wheelbase 7'2" ( O/A wheelbase 7'2" + 6'10") 0-4-2 F - WD. 5'. Coupled wheelbase 7'9". ( O/A wheelbase 7'9" + 6'11")

I have looked through ebay to see what locos are available to use as donors for GNRi loco builds. 4-4-0 Loch class - wheel dia. 3'3", 6' 3 1/2" 4P compound - WD. 3' 6 1/2", 6' 9" 2P - WD. 3' 6 1/2", 6' 9" D49 - WD. xxxx, 6' 8" D41 - WD. 3' 9 1/2", 6' 1" T9 - WD. 3' 7", 6' 7" D16/3 - WD. 3' 9", 7' V Schools - WD. Xxxx, 6' 7" L1 - WD. 3' 7", 6' 8" 0-6-0 3F - WD. 4' 7" 1361 - WD. 3' 8" J52 - WD. 4' 8" 08 diesel - WD. 4' 6" J72 - WD. 4' 1 1/4" 2251 - WD. 5' 2" E2 - WD. 4' 6" 1600 - WD. 4' 1 1/2" J94 - WD. 4' 3" 6400 - WD. 4' 7 1/2" J83 - WD. 4' 6" J39 - WD. 5' 2" J13 - WD. 4' 10" C - WD. 5' 2" 0-4-0 GWR class 101 - WD. 3' 8" C14 - WD. 3' 0-6-2 N7/L77 - WD. 4' 10", xxxx N2 - WD. 5' 8", 3' 8" 5600 - WD. 4' 7 1/2", 3' 8"

@Mol_PMB thank you, I'll chase that up, sounds like a good source of information.

I used a Hornby class T9 to make a class Q , shouldn't be too hard to make it resemble a UG. Or if I could find a good set of plans I could draw you up a body in cad, use the T9 running gear if the wheels are the right size and have it 3d printed like my QGT.

@Mol_PMB thanks for that. What is the 1940 diagram book ?

@jhb171achillThank you.

Anyone any ideas what type of wagon this was and what did it carry ? Thanks, Noel.

Yep, easy to sort out. Do the brake levers both point in the same direction ?

Working on interior now.
